Eaton MGE UPS Protection Center 500 USB

General
MPN
66873, 66878
Device Type
UPS - external
Battery Enclosure Type
Internal
Width
36 cm
Depth
17.3 cm
Height
9.5 cm
Weight
4.3 kg
Power device
UPS Technology
Off-line
Input Voltage Range
AC 160 - 284 V, AC 184 - 264 V
Frequency Required
50/60 Hz, 46 - 70 Hz
Output Voltage
AC 230 V ( 50/60 Hz ), AC 230 V ± 7% ( 50/60 Hz )
Power Output Connectors Details
4 x power 3-pole (France/Belgium) ( UPS and surge ) ¦ 4 x power 3-pole (France/Belgium) ( surge ), 4 ( UPS and surge ) ¦ 4 ( surge )
Power Capacity
300 Watt / 500 VA
Dataline Surge Protection
Network/phone line
Surge Suppression
Standard
Surge Energy Rating
525 Joules
Circuit Protection
Circuit breaker
Output Waveform
Stepped approximation to a sinewave
Input Voltage Range (Adjustable)
AC 161 - 284 V
Input Voltage
AC 230 V
Load Rating
Individual PC
Battery
Technology
Lead Acid
Voltage Provided
12 V
Capacity
7 Ah
Run Time (Up To)
30 min
Networking
Remote Management Interface
USB
Expansion / connectivity
Interfaces
1 x management - USB
Miscellaneous
Cables Included
1 x USB cable
Features
Wall mountable , audible alarm
Compliant Standards
CE, ISO 9001, IEC 60950, ISO 14001, IEC 62040-1-1
Software / system requirements
Software Included
Personal Solution-Pac
OS Required
Microsoft Windows 95, Apple MacOS, Linux, Microsoft Windows 98/ME/2000/XP
