Popis
Model RS750-AMAAB1-xx
Type Intel
Form Factor ATX 12V V2.31
Dimension (W x L x H)150 x 140 x 86mm / 5.9 x 5.5 x 3.4 inch
Input Voltage100-240Vac (Full Range)
Input Current12 - 6A
Input Frequency Range60 - 50Hz
PFC Active PFC (gt;0.9 typical)Power Good Signal 100-500ms Hold Up Timegt;16ms
Efficiency85% TypicallyMTBFgt;100,000 Hours
ProtectionOVP/UVP/OPP/OTP/SCP/OCP
Output Capacity750W
Operation Temperature0~40°C
Regulatory CE/FCC/UL/TUV/RCM/EAC/BSMI/CCC
Certifications 80 Plus Bronze
Connector MB 20+4 Pin x 1CPU12V 4+4 Pin x 1PCI-e 6+2 Pin x 4SATA x 84Pin Peripheral x 64Pin Floppy x 1
