HP LTO-5 Ultrium media offers the best capacity/performance ratio of any tape technology, with terabyte-class capacity and performance. It has almost double the capacity and offers faster performance compared to LTO-4 Ultrium, with built-in encryption capability and a Write Once Read Many (WORM) option – with no performance overhead. It can write or read data at a blistering 1 TB/hour, storing, encrypting and protecting up to 3 TB on a single cartridge, making it the big hitter in large-scale, 24×7, mission-critical IT environments. Standardizing on HP LTO-5 Ultrium delivers the capacity to meet shrinking backup windows, industry-standard, AES 256-bit encryption (IEEE1619.1), and interchangeable RW or WORM media, without extra space or IT resource overhead.
Related products
Technical Specifications
Storage
Capacity
1.6 TB; Compressed 2:1; Supported
Media capacity compressed
1.6 TB
Media labeling
Write-on Labels in box
Media capacity native
800 GB
Bit density
343 kbits/inch
Data tracks
896
Tape width
0.49803 in
Tape width
12.65 mm
Media durability
1,000,000 passes on any area of tape, equates to over 20,000 end to end passes/260 full tape backups
Media format
Re-Writable
Tape length
820 m
Base material
Metal Particle
Tape thickness
6.6 um
Drive compatibility
Storage Media Compatibility Matrix
Drive compatibility url
http://www.hptapecompat.com
Magnetic coercivity
2600-2750 Oe
Read speed, media
240 MB/sec
Recording technology
LTO-4 Ultrium
Archival life
30 years
Environmental information
Day-to-day storage temperature 60° to 90° F (16° to 32° C)
Operating maximum wet bulb temperature 79° F (26° C)
Storage humidity 20 to 60% (Archival)
Physical information
Count of carton in pallet 960
Pallet weight 331 kg
Dimensions (W x D x H) 4.37 x 4.45 x 1.1 in
Color Green
