MATSONIC MS9147C socket 478

Processor



* Support Socket 478 for Intel(R) Pentium(R) 4

1.5GHz~2.8GHz or faster Processor

* 400/533MHz system interface speed



Chipset



* VIA P4X333 North Bridge and VT8235 South Bridge chipsets

* MuTIOL Delivering 533MB/s Bandwidth



Memory



* Supports two 184-pin DDR DIMM maximum size up to 2GB

* Supports two 168-pin SDRAM DIMM maximum size up to 2GB

* Support DIMMs of DDR333/DDR266/PC133



Ultra DMA 100/133 IDE Ports



* Supports two IDE ports up to 4 ATAPI

devices

* Supports up to PIO Mode 4 up to 16.6MBps,

Multi Mode 4 up to 133MBps with bus

mastering



Graphics Adapter Slot



* Supports AGP 4x mode



BUS ARCHITECTURE



* One CNR slot for Soft modem riser only

* Four 32-bit PCI slots with full master sharing

controller (Rev 2.2 compliant)

* One AGP4x slot



Embedded USB2.0 on board



* 480 Mbps data capacity

* Backwards compatible with USB 1.1

* Compliant with Intel’s Enhanced Host

* Controller Interface Specification Revision 0.95



FORM FACTOR



* 304mm x 244mm, 4 Layers

* ATX form factor





CMI9738/4CH AC 97 CODEC



* Supports built-in AC97 Digital Audio.

Dual full-duplex Direct Sound channels.

H/W Sound Blaster Pro DOS Legacy compatibility.

FM Synthesis for legacy compatibility.

* Supports game or MIDI port



I/O INTERFACE



* PS/2 Mini-DIN keyboard and mouse ports

* Six USB ports (two backpanel ports, onboard USB headers providing four extra ports)

* Two D-SUB 9-pin male serial ports

* One D-SUB 25-pin female Printer port

* One D-SUB 15-pin female Game/MIDI port

* Audio Line-out, Line-in and Mic-in jacks



SYSTEM BIOS



* 2MB Flash Rom on board, provides complete Advances Configuration Power Interface (ACPI) and Legacy PMU

* Fully compliant to PC'97 and PC'98 Spec
