Thermaltake Standard Smart Case Fan II 12CM A2029

Feature
top


- 3 functions in 1 fan

- Smart Case Fan II (3 functions in 1) :

1. Full speed when jumper on

2. Temperature control : Fan speed varies according to the temp detected by the sensor

3. Manual control : Adjust fan speed manually

- Smart Case Fan II series in 80, 90, 120mm dimensions

- 2 ball bearing, extend the operating life

- 3 to 4 pin adaptor included, to power supply unit

- Bundle with bracket controller, attach to PCI slot
Specification
top
P/N
A2029
Fan Dimension
120 x 120 x 25 mm
Started Voltage
7V
Rated Voltage
12V
Power Input
0.96 ～ 5.76W
Fan Speed
800±400 RPM at 20C ～

2650±10％ RPM at 55C
Max. Air Flow
35.20 ～ 120.68 CFM
Max. Air Pressure
0.94 ～ 7.78 mmH2O
Noise
22.5 dBA at 800RPM ～

46.4dBA at 2650RPM
Bearing Type
2-Ball Bearing
Life Expectation
50,000 Hours
Connector
3 Pin
Weight
152g
* Specifications are subject to change without notice.

* The product picture(s) is only for your reference, it may differ from the actual product.
