Intel Wi-Fi 6 AX201 Gig+

Essentials
Download Specifications
Product CollectionIntel® Wi-Fi 6 Series
Code NameProducts formerly Harrison Peak
Marketing StatusLaunched
Launch Date Q2'19
Weight (in grams)2.33
Operating Temperature Range0 °C to 50 °C
Supported Operating SystemsWindows 11, 64-bit*, Windows 10, 64-bit*, Linux*, Chrome OS*
Antenna2x2
Supplemental Information
Product BriefView now
Networking Specifications
TX/RX Streams2x2
Bands2.4, 5 GHz (160MHz)
Max Speed2.4 Gbps
Wi-Fi CERTIFIED*Wi-Fi 6 (802.11ax)
ComplianceFIPS, FISMA
Integrated BluetoothYes
Bluetooth Version 5.2
Package Specifications
Board Form FactorM.2 2230, M.2 1216
Package Size22mm x 30mm x 2.4mm, 12mm x 16mm x 1.65mm
System Interface TypeM.2: CNVio2
Advanced Technologies
MU-MIMO Yes
Orthogonal Frequency-Division Multiple Access (OFDMA) Yes
Supported Under Intel vPro® TechnologyYes
