Samtron 56E

GENERAL
Dimensions (WxDxH)14 in x 14.6 in x 14.9 in
Display TypeCRT monitor / CRT
Native Resolution1024 x 768 at 68 Hz
Controls & AdjustmentsBrightness, contrast, H/V moire, H/V position, H/V size, trapezoid, degauss, color temperature, parallelogram, pincushion, pin balance, zoom, V linearity
Color Temperature9300K, 6500K
Viewable Size13.8"
Pixel Pitch0.24 mm
Screen CoatingMulti-layer coating
Horizontal Refresh Rate55 kHz
Video Bandwidth65 MHz
Vertical Refresh Rate120 Hz
ManufacturerSamsung
CONNECTIVITY
Interfaces1 x VGA - 15 pin HD D-Sub (HD-15)
POWER DEVICE
Typepower supply
Nominal VoltageAC 120/230 V
Frequency Required50/60 Hz
DISPLAY
Video Bandwidth65 MHz
TypeCRT monitor
MISCELLANEOUS
Compliant StandardsPlug and Play, MPR II, CSA, UL, TUV, TUV GS, VCCI, C-Tick, BSMI, CCIB, ICES-003, IEC950, NEMKO
Controls & AdjustmentsH/V moire, H/V position, H/V size, V linearity, brightness, color temperature, contrast, degauss, parallelogram, pin balance, pincushion, trapezoid, zoom
POWER
Power Consumption Stand by / Sleep3 Watt
Power Supplyinternal
INTERFACE PROVIDED
Qty1
Connector Type15 pin HD D-Sub (HD-15)
VIDEO
Video Outputnone
SYSTEM REQUIREMENTS
OS RequiredMicrosoft Windows 98/ME/2000
DIMENSIONS & WEIGHT
Width14 in
Depth14.6 in
Height14.9 in
Weight25.35 lbs
HEADER
BrandSAMTRON
Product LineSAMTRON
Model56E
Packaged Quantity1
CompatibilityMac, PC
PROJECTOR
Max V-Sync Rate120 Hz
Max H-Sync Rate55 KHz
TV TUNER
TV Tuner PresenceNoGENERAL
ManufacturerSamsung
