SPECS
GENERAL
Display TypeCRT monitor / CRT
CRT TypePerfectFlat - shadow mask
Native Resolution1792 x 1344
Controls & AdjustmentsBrightness, contrast, H/V moire, H/V position, H/V size, tilt, trapezoid, degauss, color temperature, parallelogram, pincushion, pin balance, zoom
Dimensions (WxDxH)17.5 in x 18.3 in x 16.7 in
Color Temperature9300K, 5000K, 6500K
Viewable Size18"
Pixel Pitch0.2 mm
Screen CoatingAnti-reflective, anti-static
Horizontal Refresh Rate86 kHz
Video Bandwidth210 MHz
Vertical Refresh Rate160 Hz
ManufacturerViewSonic
CONNECTIVITY
Interfaces1 x VGA - 15 pin HD D-Sub (HD-15)
POWER DEVICE
Nominal VoltageAC 120/230 V
Frequency Required50/60 Hz
Power Consumption Operational55 Watt
POWER
Power Supplyinternal
INTERFACE PROVIDED
Qty1
Connector Type15 pin HD D-Sub (HD-15)
MISCELLANEOUS
Compliant StandardsMPR II, DDC-1, DDC-2B, SASO, CB, CCC
Controls & AdjustmentsH/V moire, H/V position, H/V size, brightness, color temperature, contrast, degauss, parallelogram, pin balance, pincushion, tilt, trapezoid, zoom
DISPLAY
Video Bandwidth210 MHz
TypeCRT monitor
DIMENSIONS & WEIGHT
Width17.5 in
Depth18.3 in
Height16.7 in
Weight39.68 lbs
ENVIRONMENTAL PARAMETERS
Min Operating Temperature32 °F
Max Operating Temperature104 °F
Humidity Range Operating5 - 95%
HEADER
BrandViewSonic
Product LineViewSonic
ModelE96f+SB
Packaged Quantity1
CompatibilityMac, PC
PROJECTOR
Max V-Sync Rate160 Hz
Max H-Sync Rate86 KHz
Viac z kategórie
Doplnkové informácie
| Kategória: | Monitor CRT |
| Rozlíšenie displeja a pomer strán: | 1600x1200 UXGA 4:3 |
| Typ panelu: | CRT |
| Rozhranie (video signál): | VGA |
| Audio vstup (reproduktory): | Nie |
| Webkamera: | Nie |
| TV Tuner: | Nie |
| Dotykový displej: | Nie |
