CPU
LGA 775 for Intel® Pentium® 4 / Pentium® D*processor
(PS:"*"Supports Intel 805, 820,920 and lower frequency)
Front Side Bus
800/533 MHz FSB
Chipset
North bridge: SiS661FX
South bridge: SiS964 MuTIOL® Media I/O
Realtek ALC633 Codec chip
ICS1883 LAN PHY chip
Memory
Type: DDR400/DDR333/DDR266
Max capacity: 2GB
DIMM slots:2
Expansion Slots
1 x AGP 8X/4X slot
3 x PCI slots (PCI 2.2 compliant)
Internal I/O Connectors
2 x Serial ATA ports
2 x USB2.0 connectors (4 ports by cable)
S/P DIF output connector (by optional cable)
2 x UDMA ATA 133/100/66 Bus Master IDE ports
1 x FDD port
CD in connector
1 x COM port
Back Panel Connectors
1 x VGA port
4 x USB 2.0 ports
1 x RJ45 LAN port
1 x LPT port
3 x Audio ports (Line-in/Line-out/MIC)
1 x COM port
2 x PS/2 ports (Keyboard/Mouse)
H/W Monitoring
System health status auto-detect and report by BIOS
Hardware detecting and reporting for Case open and CPU and System fan speed
BIOS
2M bit flash ROM
Form Factor
Micro ATX
23.0 x 24.4 cm
+I/O shield krytka
