Specifications
GPU 4096 Stream Processors
28 nm
950 MHz Engine Clock
1000 MHz Boost Engine Clock
Interface PCI-Express 3.0
Memory 768 bit Memory Bus
GDDR5 Memory Type
6000 MHz Effective
6 GB Size
BIOS Support Legacy BIOS
Displays Maximum 5 Outputs
Output 1 x DVI-I
4 x Mini DisplayPort
Resolution
API OpenGL® 4.2
DirectX® 12
Shader Model 5.0
Feature
Cooling Active Cooling
Form Factor 2 Part Slot Occupied
305(L)x100(W)x38(H) Dimension /mm
Power Consumption
OS
System Requirement 750 Watt Power Supply (Suggestion)
1000 Watt Power Supply is recommended for CrossFireX™ System
4096 MB Minimum of system memory
CD-ROM or DVD-ROM drive for installing software
PCI Express® 2.0 or higher version based PC is required with one X16 lane graphics slot available on the motherboard in order for the card to be compatible with.
