Intel® Xeon® Procesor W3565 8M Cache, 3.20 GHz, 4.80 GT/s Intel® QPI

Essentials

Product Collection Intel® Xeon® Processor 3000 Sequence
Code Name Products formerly Bloomfield
Vertical Segment Server
Processor Number W3565
Status End of Life
Launch Date Q4'09
Lithography 45 nm
Recommended Customer Price $305.00

Performance

# of Cores 4
# of Threads 8
Processor Base Frequency 3.20 GHz
Max Turbo Frequency 3.46 GHz
Cache 8 MB SmartCache
Bus Speed 4.8 GT/s QPI
# of QPI Links 1
TDP 130 W
VID Voltage Range 0.800V-1.225V

Supplemental Information

Embedded Options Available No
Datasheet View now

Memory Specifications

Max Memory Size (dependent on memory type) 24 GB
Memory Types DDR3 800/1066
Max # of Memory Channels 3
Max Memory Bandwidth 25.6 GB/s
Physical Address Extensions 36-bit
ECC Memory Supported ‡ Yes

Package Specifications

Sockets Supported FCLGA1366
Max CPU Configuration 1
Package Size 42.5mm x 45.0mm
Processing Die Size 263 mm2
# of Processing Die Transistors 731 million
Low Halogen Options Available See MDDS

Advanced Technologies

Intel® Turbo Boost Technology ‡ 1.0
Intel® Hyper-Threading Technology ‡ Yes
Intel® Virtualization Technology (VT-x) ‡ Yes
Intel® VT-x with Extended Page Tables (EPT) ‡ Yes
Intel® 64 ‡ Yes
Instruction Set 64-bit
Instruction Set Extensions SSE4.2
Idle States Yes
Enhanced Intel SpeedStep® Technology Yes
Intel® Demand Based Switching Yes
Thermal Monitoring Technologies No

Intel® Data Protection Technology

Intel® AES New Instructions No

Intel® Platform Protection Technology

Trusted Execution Technology ‡ No
Execute Disable Bit ‡ Yes
