150Mbps wireless data rates ideal for video streaming, online gaming and internet calling
Tiny - Ideal for home and travel use
Supports AP (default), Client, Router, Repeater and Bridge modes
Powered through a micro USB port by an external power adapter or USB connection to a computer
HARDWARE FEATURES
Interface 1 10/100Mbps WAN/LAN Port
1 Micro USB Port
1 Reset Button
Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Dimensions ( W x D x H ) 2.2 x 2.2 x 0.7 in. (57 x 57 x18 mm)
Antenna Type On-Board
WIRELESS FEATURES
Frequency 2.4-2.4835GHz
Signal Rate 11n: Up to 150Mbps(dynamic)
11g: Up to 54Mbps(dynamic)
11b: Up to 11Mbps(dynamic)
Reception Sensitivity 135M:-70dBm@10%PER
65M:-73dBm@10%PER
54M:-76dBm@10%PER
Transmit Power CE:
<20dBm(2.4GHz)
FCC:
<30dBm
Wireless Modes AP Mode, Router Mode ,Client Mode,
Repeater Mode, Bridge Mode
Wireless Functions Enable/Disable Wireless Radio, WDS Bridge, WMM,
Wireless Statistics
Wireless Security 64/128/152-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
SOFTWARE FEATURES
Quality of Service WMM, Bandwidth Control
WAN Type Dynamic IP/Static IP/PPPoE/
PPTP/L2TP
Management Local Management
Remote Management
DHCP Server, Client, DHCP Client List,
Address Reservation
Port Forwarding Virtual Server, Port Triggering, UPnP, DMZ
Dynamic DNS DynDns, Comexe, NO-IP
VPN Pass-Through PPTP, L2TP, IPSec (ESP Head)
Access Control
Firewall Security DoS, SPI Firewall
IP Address Filter/MAC Address Filter/Domain Filter
IP and MAC Address Binding
OTHERS
Certification FCC, RoHS
Package Contents TL-WR702N
Power Adapter
USB Cable
System Requirements Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7, Windows8/ 8.1/10
MAC® OS, NetWare®, UNIX® or Linux
Environment Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
