TYAN® GT20-B7002 is a highly-optimized rack-mountable barebone system. GT20-B7002 is designed to support up to two Intel® "Nehalem-EP 2S" processors and up to 64GB DDR3-800/1066/1333 memory, providing a rich feature set and incredible performance. Leveraging advanced technology from Intel®, GT20-B7002 server system is capable of offering scalable 32 and 64-bit computing, high bandwidth memory design, and lightning-fast PCI-E bus implementation. GT20-B7002 not only empowers your company in nowadays IT demand but also offers a smooth path for future application usage.
Specifications:
System Form Factor 1U Rackmount
Chassis Name GT20
Dimension (D x W x H) 22.4" x 17.2" x 1.72" (568 x 436 x 43.6mm)
Motherboard S7002GM2NR-LE
Gross Weight 16 kg
Front Panel Buttons (1) RST / (1) NMI / (1) ID / (1) PWR w/ LED
LEDs (1) HDD / (2) LAN / (1) ID / (1) Warning / (1) Reserved
I/O Ports (2) USB ports
External Drive Bay Type / Q'ty 3.5" Hot-Swap / (4)
Supported HDD Interface SATA-II 3.0Gb/s
System Cooling Configuration FAN (5) 4cm fans
Power Supply Type EPS1U
Input Range Full-range AC(100-240V)
Frequency 47 - 63 Hertz
Output Watts 400 Watts
Efficiency PFC / 80-plus
Processor Supported CPU Series Intel Xeon Processor 5500 Series
Socket Type / Q'ty LGA1366 / (2)
Thermal Design Power (TDP) wattage 95W
System Bus Up to 4.8/ 5.86/ 6.4GT/s with Intel QuickPath Interconnect (QPI) support
Chipset IOH / ICH Intel 5500 / ICH10R
Super I/O Winbond W83627
Memory Supported DIMM Qty (8) DIMM slots
DIMM Type / Speed DDR3 800/1066/1333* RDIMM/UDIMM / * limit 1 per channel for 1333MHz speed
Capacity Up to 64GB
Memory channel 6 Channels (3 Channels per CPU)
Memory voltage 1.5V
Expansion Slots PCI-E (1) PCI-E Gen.2 x16 slot
Pre-install TYAN Riser Card M2083-RS, PCI-E x16 1U riser card (left)
LAN Port Q'ty (2)
Controller Intel 82574L
Storage SATA Controller ICH10R
Speed 3.0 Gb/s
RAID RAID 0/1/10/5 (Intel Matrix RAID)
Graphic Connector type D-Sub 15-pin
Resolution 1600x1200@60Hz
Chipset Aspeed AST2050
I/O Ports USB (6) ports (2 at front, 4 at rear)
COM (1) DB-9 COM port
VGA (1) D-Sub 15-pin port
RJ-45 (2) ports
System Monitoring Chipset Winbond W83793G
Voltage Monitors voltage for CPU, memory, chipset & power supply
Temperature Monitors temperature for CPU & system environment
LED Fan fail LED indicator / Over temperature warning indicator
Others Watchdog timer support
Server Management Onboard Chipset Onboard Aspeed AST2050
AST2050 IPMI Feature IPMI 2.0 compliant baseboard management controller (BMC) / Supports storage over IP and remote platform-flash/ BIOS update / USB 2.0 virtual hub
AST2050 iKVM Feature 24-bit high quality video compression / Dual 10/100 Mb/s MAC interfaces
BIOS Brand / ROM size AMI / 2MB
Feature Plug and Play (PnP) /PCI2.3 /WfM2.0 /SMBIOS2.3 /PXE boot / ACPI 2.0 power management /Power on mode after power recovery / User-configurable H/W monitoring / Auto-configurable of hard disk types / Multiple boot options
Operating System OS supported list Please refer to our OS supported list.
Regulation FCC (DoC) Class A
CE (DoC) Yes
Operating Environment Operating Temp. 10° C ~ 35° C (50° F~ 95° F)
Non-operating Temp. - 40° C ~ 70° C (-40° F ~ 158° F)
In/Non-operating Humidity 90%, non-condensing at 35° C
RoHS RoHS 6/6 Complaint Yes
Package Contains Motherboard (1) S7002GM2NR-LE Motherboard
Barebone (1) GT20B7002 Barebone
Manual (1) MB User's manual + (1) BB User's manual
Installation CD (1) TYAN installation CD
Heatsink / Cooler (2) CHSK-0370, LGA1366 CPU heatsinks
Rail kit (1) CRAL-0032, sliding rail kit for KGT20
Mounting Ear (1) CEAR-0120, mounting ear kit
Backplane (1) M1232, 4-port SAS/SATA HDD backplane and fan control board
Others (1) screw pack
Cable Power Cord (1) CCBL-0310, US type power cord / (1) CCBL-0300, EU type power cord
Optional accessories for future upgrade Front Bezel (1) CFBZ-0070, Front bezel for GT series 1U chassis
Peripheral (1) CDVD-0060, slim type DVD-ROM / (1) CCBL-0422, slim ODD SATA cable
