Detail Specification
The Specification may change without notice. The actual products sold are different from areas. Please check the detailed Specification with your local dealers.
Basic Specification
|
Detail Specification
CPU
• Supports Socket A (Socket 462) for AMD® Athlon™ XP/Athlon™/Duron™ processor
• Supports to Athlon™ XP 3200+ processor or higher speed
• Supports 200/266/333/400MHz FSB
Chipset
• VIA® KT600 Chipset
- FSB @200/266/333/400MHz
- Supports DDR200/266/333/400 memory
- AGP 8X and PCI advanced high performance memory controller.
• VIA® VT8237 Chipset
- Ultra DMA 66/100/133 master mode EIDE controller.
- Intergrated dual channel native Serial ATA/RAID controller
supplying 150MB/s supporting for RAID 0 and RAID 1
- ACPI PC2001 compliant enhanced power management.
- Supports 8 USB 2.0 ports
Main Memory
• Supports six memory banks using three 184-pin DDR DRAMs.
• Supports up to 3GB memory size.
• Supports DDR400/DDR333/DDR266/DDR200 DRAM
Note: PC3200 (DDR400) maximum 4 banks only.
Slots
• One AGP (Accelerated Graphics Port) slot.
- Supports AGP 4x/8x.
- Supports AGP 3.0
• Five 32-bit PCI bus slots (support 3.3v/5v PCI bus interface).
On-Board IDE
• An IDE controller on the VT8237 chipset provides IDE HDD/CD-ROM with PIO, Bus Master and
Ultra DMA 133/100/66 operation modes.
- Can connect up to four Ultra ATA drives.
• Serial ATA/150 controller integrated in VT8237.
- Up to 150MB/sec transfer speeds.
- Can connect up to two Serial ATA drives.
- Supports RAID 0 or RAID 1.
Promise 20378 On-Board
• Supports Ultra ATA, Serial ATA, Ultra ATA RAID 0 or 1 , Serial ATA RAID 0
or 1, Ultra/Serial ATA RAID 0+1 supported.
• Connect up to 2 Serial ATA devices and 2 Ultra ATA 133 devices.
Audio
6 channels software audio codec C-Media 9739A.
- Compliance with AC97 v2.2 Spec.
- Meet PC2001 audio performance requirement.
- Can support SPDIF Out via optional S-Bracket only.
LAN
Broadcom 4401/5788
- Integrated Gigabit Ethernet MAC and PHY transceiver, auto-negotiation operation.
- Supports single-port 10MB/s, 100MB/s (for 4401) or 1000MB/s (for 5788) BAST-T application.
- Compliance with PCI v2.2 and LAN on Motherboard (LOM) standard.
On-Board Peripherals
On-Board Peripherals include:
- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and 2.88Mbytes
- 2 serial ports (COM A + COM B)
- 1 parallel port supports SPP/EPP/ECP mode
- 1 IrDA connector for SIR/ASKIR/HPSIR
- 1 audio port
- 8 USB 2.0 ports (Rear x 6 / Front x 2)
BIOS
• The mainboard BIOS provides "Plug Play" BIOS which detects the peripheral devices
and expansion cards of the board automatically.
• The mainboard provides a Desktop Management Interface(DMI) function which records
your mainboard specifications.
Dimension
• 30.5 cm(L) x 23.5 cm(W) ATX Form Factor
Mounting
• 6 mounting holes.
