Popis
Processor
Support Socket 478 for Intel(R) Pentium(R) 4 1.5GHz~2.8GHz or faster Processor 400/533MHz system interface speed
Chipset
SIS 650GL North Bridge and SIS 962L South Bridge chipsets MuTIOL� Delivering 533MB/s Bandwidth
Memory
Supports two 184-pin DDR DIMM maximum size up to 2GB Supports two 168-pin SDRAM DIMM maximum size up to 2GB Support DIMMs of DDR266/PC133
Bus Architecture
One ACR slot (Audio Communication Riser) Four 32-bit PCI slots with full master sharing controller (Rev2.2 compliant) One AGP4x slot One AGP4x slot
I/O Interface
PS/2 Mini-DIN keyboard and mouse ports Six USB ports (two backpanel ports, onboard USB headers providing four extra ports) Two D-SUB 9-pin male serial ports One D-SUB 25-pin female Printer port One D-SUB 15-pin female Game/MIDI port Audio Line-out, Line-in and Mic-in jacks
System BIOS
2MB Flash Rom on board, provides complete Advances Configuration Power Interface (ACPI) and Legacy PMU Fully compliant to PC'97 and PC'98 Spec
CMI9738/4CH AC�97 CODEC
AC97 Codec on board to provide software audio solution 4CH DAC, applicable for leading motherboard chipsets. 48 LQFP package(pin to pin compatible with 2-channel CODEC) and 24-lead TSSOP package.
Embedded USB2.0 on board
480 Mbps data capacity Backwards compatible with USB 1.1 Compliant with Intel�s Enhanced Host Controller Interface Specification Revision 0.95
Graphics Adapter Slot
Support AGP4X Interface
Embedded 3D Ultra AGP VGA
Integrated Real256TM 2D/3D Graphics Accelerator Shared memory architecture allows a maximum of 64 MB main memory to act as frame buffer
Ultra DMA 100/133 IDE Ports
Supports two IDE ports up to 4 ATAPI devices Supports up to PIO Mode 4 up to 16.6MBps, Multi Mode 4 up to 133MBps with bus mastering
Form Factor and Layers
Standard ATX form factor Four layers. 304mm x 244mm, 4 Layers
Support Socket 478 for Intel(R) Pentium(R) 4 1.5GHz~2.8GHz or faster Processor 400/533MHz system interface speed
Chipset
SIS 650GL North Bridge and SIS 962L South Bridge chipsets MuTIOL� Delivering 533MB/s Bandwidth
Memory
Supports two 184-pin DDR DIMM maximum size up to 2GB Supports two 168-pin SDRAM DIMM maximum size up to 2GB Support DIMMs of DDR266/PC133
Bus Architecture
One ACR slot (Audio Communication Riser) Four 32-bit PCI slots with full master sharing controller (Rev2.2 compliant) One AGP4x slot One AGP4x slot
I/O Interface
PS/2 Mini-DIN keyboard and mouse ports Six USB ports (two backpanel ports, onboard USB headers providing four extra ports) Two D-SUB 9-pin male serial ports One D-SUB 25-pin female Printer port One D-SUB 15-pin female Game/MIDI port Audio Line-out, Line-in and Mic-in jacks
System BIOS
2MB Flash Rom on board, provides complete Advances Configuration Power Interface (ACPI) and Legacy PMU Fully compliant to PC'97 and PC'98 Spec
CMI9738/4CH AC�97 CODEC
AC97 Codec on board to provide software audio solution 4CH DAC, applicable for leading motherboard chipsets. 48 LQFP package(pin to pin compatible with 2-channel CODEC) and 24-lead TSSOP package.
Embedded USB2.0 on board
480 Mbps data capacity Backwards compatible with USB 1.1 Compliant with Intel�s Enhanced Host Controller Interface Specification Revision 0.95
Graphics Adapter Slot
Support AGP4X Interface
Embedded 3D Ultra AGP VGA
Integrated Real256TM 2D/3D Graphics Accelerator Shared memory architecture allows a maximum of 64 MB main memory to act as frame buffer
Ultra DMA 100/133 IDE Ports
Supports two IDE ports up to 4 ATAPI devices Supports up to PIO Mode 4 up to 16.6MBps, Multi Mode 4 up to 133MBps with bus mastering
Form Factor and Layers
Standard ATX form factor Four layers. 304mm x 244mm, 4 Layers
