ASRock 4CoreDual-SATA2 R2.0

LGA 775 for Intel® Core™ 2 Extreme / Core™ 2 Quad / Core™ 2 Duo / Pentium® XE / Pentium® D / Pentium® Dual Core / Pentium® 4 / Celeron® / Celeron® D, supporting Quad Core Kentsfield processorsVIA® PT880 Pro/PT880 Ultra ChipsetsSupports FSB1066/800/533MHz processors and H-T TechnologySupports Dual Channel DDR2 667 (DDR2 x 2 DIMM slots) and DDR400 (DDR x 2 DIMM slots)Untied Overclocking : During Overclocking, FSB enjoys better margin due to fixed AGP/PCIE/ PCI Buses1 x PCI Express Graphics slot (@ x4 mode)1 x AGP 8X slotHybrid Booster - Safe Overclocking Technology2 x SATA2 3.0 Gb/s connectors, support RAID (RAID 0, RAID 1, and JBOD) and Hot Plug functionsHDMI_SPDIF header, providing SPDIF audio output to HDMI VGA card, allows the system to connect HDMI Digital TV/projector/LCD devices.10/100 Ethernet LANSupports all features in Windows® Vista™ PremiumASRock 6CH Premium I/O: 4 ready-to-use USB 2.0 ports, High Definition AudioThis model may not be sold worldwide. Please contact your local dealer for the availability of this model in your region.
Product Specifications GeneralCPU- LGA 775 for Intel® Core™ 2 Extreme* / Core™ 2 Quad* / Core™ 2 Duo / Pentium® XE / Pentium® D / Pentium® Dual Core / Pentium® 4 / Celeron® / Celeron® D, supporting Quad Core Kentsfield processors- FSB 1066/800/533 MHz- Supports Hyper-Threading Technology- Supports Untied Overclocking Technology- Supports EM64T CPU
*When you adopt Quad Core CPU, FSB may be reduced 5%Chipset- Northbridge: VIA® PT880 Pro/PT880 Ultra- Southbridge: VIA® VT8237SMemory- Dual Channel DDR/DDR2 memory technology*- 2 x DDR2 DIMM slots- Supports DDR2 667/533 non-ECC, un-buffered memory- Max. capacity: 2GB- 2 x DDR DIMM slots- Supports DDR400/333/266 non-ECC, un-buffered memory- Max. capacity: 2GB
*DDR2 and DDR are supported separatelyBIOS- 4Mb AMI BIOS- AMI Legal BIOS- Supports "Plug and Play"- ACPI 1.1 Compliance Wake Up Events- Supports Jumperfree- SMBIOS 2.3.1 Support Audio, Video and NetworkingGraphics- n/aAudio- 5.1 CH Windows® Vista™ Premium Level HD Audio (ALC662 Audio Codec)LAN- VIA® PHY VT6103- Speed: 10/100 Ethernet- Supports Wake-On-LAN- Supports PXE Expansion / ConnectivitySlots- 1 x PCI Express Graphics slot (@ x4 mode)- 1 x AGP 8X slot- 4 x PCI slotsConnector- 2 x SATA2 3.0 Gb/s connectors, support RAID (RAID 0, RAID 1 and JBOD) and Hot Plug functions- 2 x ATA133 IDE connectors (support 4 x IDE devices)- 1 x Floppy connector- 1 x IR header- 1 x Game header- 1 x HDMI_SPDIF header- CPU/Chassis FAN connector- 20 pin ATX power connector- 4 pin 12V power connector- CD in header- Front panel audio connector- 2 x USB 2.0 headers (support 4 USB 2.0 ports)Rear Panel I/OASRock 6CH Premium I/O- 1 x PS/2 Mouse Port- 1 x PS/2 Keyboard Port- 1 x Serial Port: COM1- 1 x Parallel Port (ECP/EPP support)- 4 x Ready-to-Use USB 2.0 Ports- 1 x RJ-45 LAN Port- HD Audio Jack: Rear Speaker / Central / Bass / Line in / Front Speaker / Microphone Other Features / MiscellaneousUnique FeatureHybrid Booster:- CPU Frequency Stepless Control- ASRock U-COP- Boot Failure Guard (B.F.G.)Support CD- Drivers, Utilities, AntiVirus Software (Trial Version)Accessories- Quick Installation Guide, Support CD, I/O Shield- Floppy/ATA 133 Cables- 1 x SATA Data Cable - 1 x SATA 1 to 1 Power Cable - 1 x HDMI_SPDIF CableHardware Monitor- CPU Temperature Sensing- Chassis Temperature Sensing- CPU Fan Tachometer- Chassis Fan Tachometer- CPU Quiet Fan- Voltage Monitoring: +12V, +5V, +3.3V, VcoreForm Factor- ATX Form Factor: 12.0-in x 9.6-in, 30.5 cm x 24.4 cmOS- Microsoft® Windows® 7 / 7 64-bit / Vista™ / Vista™ 64-bit / XP / XP 64-bit / 2000 compliantCertifications- FCC, CE, WHQL
