Specifications
Port Attributes
16 10/100Mbps Ethernet ports
Auto MDI/MDIX
Auto-Negotiation: Speed, Duplex Mode, and Flow Control
Dimension
185mm (W) X 124mm (D) X 45mm (H)
LED
POWER:
Green-Power on
OFF-Power off
STATUS:
Green-Link
Blinking-TRANSMIT/RECEIVE
Performance
Up to 4,096 MAC Address with automatic address learning and aging.
Full wire-speed switching on all ports
Switching Fabric: 3.2Gbps
Features
Stored-and -forward
Back-pressure in half-duplex and flow control in full-duplex operation
Power Supply
Power Adaptor: AC 9VAC /1.5A, 13.5W
Environmental Specification
Operating temperature: 0°C~45°C
Storage temperature: -20°C ~ 70°C
Operating humidity: 20% ~85%
Storage humidity: 5% ~95%
Safety
UL1950, CCC
EMC
CE, FCC, VCCI, C-Tick MIC, CCC
