ABIT Fatal1ty X800 XL

Features
Core Clock :400MHz

0.11 micron process

Up to 16 extreme parallel pixel pipelines

256-bit quad-channel GDDR3 memory interface

6 programmable vertex shader pipelines

20% to 40% performance increase (FPS) at highest visual setting: 1600X1200.

ATI SMSRTSHADER™ HD Technology

ATI SMARTVISION™ HD Technology

ATI 3Dc™ compress Technology

ATI Hyper Z™ HD Technology

ATI VIDEOSHADER™ HD Technology

Fully PCI Express x16 spec 1.0a compatible

Dual integrated display controllers

Dual integrated 10 bit per channel 400 MHz DACs

Integrated 165 MHz TMDS transmitter

Maximum 3D Resolutions to 2048 X 1536Hz

Integrated TV Output support up to 1024x768 resolution

ABIT Engineered XTurbo™ Overclocking

ABIT 1 click Overclocking Technology

Dual BIOS for enhanced reliability

Superior power design for optimal overclocking performance

ABIT owned design circuit secured overclocking performance Large 6cm ball-bearing Cooper FAN with RAM sink

ABIT vGuru™ Technology

OC Guru ™ overclocking utility for core and memory clock and voltage

ABIT EQ™ hardware monitoring

ABIT FAN EQ™

BlackBox™ e-service

I/O Interface
DVI Connector

VGA Connector

TV-Out Connector

ABIT Original 1 Click OC Switch

Bundled Software
Installation CD (PowerDVD 5 Software Included)

Package Contents
Fatal1ty X800 XL 512MB Graphics Accelerator

User's manual

vGuru™ manual

Accessories

DVI to VGA adapter

S-Video Extension Cable

Composite Cable

PCI Express Power Extension cable

System Requirements
350-Watt power supply or higher recommended

Intel® Pentium® 4 LGA775 / AMD® Athlon® 64 or higher CPUs supported MB with One available PCI Express X 16 slot

256MB system memory

CD-ROM or DVD-ROM drive

Operating System
Windows® XP/2000
