Processor Intel® Core™2 Extreme, Core™2 Duo, Pentium® Dual-Core, Pentium® D, Pentium® 4, Celeron® D, Celeron® processors, Socket T (LGA775)
Chipset Intel® 945GC + ICH7
Front Side Bus 1066(oc*) / 800 / 533 MHz FSB
Memory Dual channel DDR2 667/533/400 x 2 DIMMs, Max. 4GB
VGA on Die Integrated
Expansion Slots 1 x PCIe x16, 1 x PCIe x1, 2 x PCI
IDE ATA 100 x 1
Serial ATA(SATA)/RAID SATAII x 4
Audio 5.1 HD audio with Realtek® ALC883
LAN 10/100M LAN by Realtek® RTL8100C
IEEE1394 N/A
Back Panel I/O Ports 1 set 5.1 channel Audio jacks (3 jacks)
1x Parallel port
1x VGA port
1x PS/2 keyboard port
1x PS/2 mouse port
4x USB 2.0 ports
1x RJ45 LAN jack
1x Serial port
Internal I/O Connectors 24-Pin power connector
4-pin 12V power connector
CPU Fan / System Fan connectors
1x CD-in connector
1x IDE connector
1x IRDA
1x Buzzer
1x Front Panel connector
2x USB 2.0 connectors support additional 4 ports
1x Intel Azalia header
4x SATAII connectors
1x Speaker (Reserved)
1x S/PDIF Out header (Reserved)
1x Intruder header
1x Floppy connector
BIOS Features 4Mb flash EEPROM w/ LAN boot PnP, ACPI, WfM, DMI
Support CD Drivers, DirectX, Adobe Reader, SuperUtilities, Norton Internet Security
Standards/Manageability PCI 2.3, USB2.0, DMI 2.5
Special Features * Achieved by overclocking
Form Factor Micro ATX (9.6" x 8.8")
+I/O shield krytka
